BVS-QG185WL 18.5-inch Embedded Industrial Panel PC, IP65 Front, Intel Core i5, 8GB+128GB, 1366×768 Capacitive Touch, Fanless Aluminum Case, Windows 10 for HMI & Machine Control
Descrizione
Overview &Key Features
【Model】BVS-QG185WL
【Item】
BVS‑QG‑185WL focuses on large‑screen upgrade requirements for semi‑automated medium‑size workshops. Its front bezel adopts a smooth hole‑free design with zero pre‑drilled fixing holes. Install the unit from the cabinet exterior, and the bezel shoulder bears the positioning load without exposed screws. It avoids the high cost of seamless cabinet customization for factory transformation projects. Equipped with the 6th‑gen Intel Core i5 CPU and dual‑OS compatibility, it delivers a practical large‑screen monitoring solution for gradually upgraded production workshops.
【Notice】
For custom specifications or wholesale inquiries, please contact our sales team.
Payment Terms:
-
Sample orders: 100% upfront
-
Bulk orders: 30% deposit, 70% balance before shipment
Lead Times:
-
Samples: 7 working days after payment confirmation
-
Bulk orders: shipping schedule to be negotiated
Shipping:Freight costs are borne by the buyer. Contact us for a quote.
Warranty: 2-year standard warranty included.
【Parameter List】
| Standard | optional | ||||||||||
| System | CPU | Intel Core i5-4200U (4th Gen) | Intel Core i3/i5/i7 (Gen 3/4/5/6/8/12) | ||||||||
| Frequency | 1.6 GHz (Up to 2.6 GHz) | / | |||||||||
| RAM | 8GB | 4GB / 8GB / 16GB | |||||||||
| SSD | 128GB | 64GB / 128GB / 256GB / 512GB | |||||||||
| Operating system | Windows 10 Pro | Windows 7 / Windows 11 / Linux | |||||||||
| Display | Screen | Industrial LCD Screen | / | ||||||||
| Resolution | 1366*768 | / | |||||||||
| Viewing angle | Ultra-Wide / Full Viewing Angle | / | |||||||||
| Contrast ratio | 1000:1 | / | |||||||||
| Brightness | 250 cd/m2 | 300/500/1000 cd/m2 | |||||||||
| Screen scale | 16:09 | / | |||||||||
| Network | Wi-Fi | / | Single-band / Dual-band | ||||||||
| Ethernet | 1 x Gigabit Ethernet | / | |||||||||
| BT | / | Bluetooth 5.0 | |||||||||
| 4G LTE | / | Mobile / Unicom / Telecom | |||||||||
| Interfaces | USB | USB 2.0 * 2, USB 3.0 * 2 | / | ||||||||
| COM | COM * 4 (Expandable) | / | |||||||||
| HD | 1 | / | |||||||||
| VGA | 1 | / | |||||||||
| TF card slot | / | / | |||||||||
| LAN | 1 | Customizable2* | |||||||||
| SIM-4G | / | Customizable1* | |||||||||
| DC-IN | 1 | / | |||||||||
| Multi-Media | Video | / | / | ||||||||
| Audio | Audio-In*1 / Audio-Out*1 | Built-in Speaker | |||||||||
| Picture | / | / | |||||||||
| Accessories | Adapter | AC 100-240V 50/60Hz, DC 12V/5A External Power Adapter | / | ||||||||
| Temperature | Working temperature | -10°C ~ 60°C | / | ||||||||
| Storage temperature | -20°C ~ 70°C | / | |||||||||
| Mounting | VESA Mount | / | Customizable | ||||||||
| Panel Mount | / | Customizable | |||||||||
| Stand Mount | / | Customizable | |||||||||
| Packaging | Net weight | / | |||||||||
| Gross weight | / | ||||||||||
| Product dimensions | 484*305*64mm（L*W*H） | / | |||||||||
| Single Unit Package Dimension | 550*145*360mm（L*W*H） | / | |||||||||
| Carton Dimension | 562*315*380（L*W*H）(Ctn Qty:5 pcs) | / | |||||||||
| Other functions | Camera | / | Customizable | ||||||||
| POE | / | Customizable | |||||||||
| OEM | Appearance, Interface, CPU, Logo, etc. | ||||||||||
Product Gallery
Applications
OEM / ODM Customization
