BVS‑QG‑104WL 10.4 Inch External Bezel Industrial Touch Panel PC, Front‑Mount Flange Design, 6th Gen Intel Core i5, Windows Linux Embedded Computer
Descrizione
Overview &Key Features
【Model】BVS-QG104WL
【Item】
BVS‑QG‑104WL adopts a raised external front bezel with pre‑drilled fixing holes for quick and convenient panel mounting. This 10.4‑inch compact industrial touch all‑in‑one PC does not require ultra‑precision cabinet processing, ideal for equipment upgrade and retrofitting projects. Equipped with the reliable 6th Gen Intel Core i5 CPU, it runs Windows and Linux stably to adapt to traditional industrial configuration software. The reinforced front bezel provides extra structural protection for frequent on‑site operation.
【Notice】
For custom specifications or wholesale inquiries, please contact our sales team.
Payment Terms:
-
Sample orders: 100% upfront
-
Bulk orders: 30% deposit, 70% balance before shipment
Lead Times:
-
Samples: 7 working days after payment confirmation
-
Bulk orders: shipping schedule to be negotiated
Shipping:Freight costs are borne by the buyer. Contact us for a quote.
Warranty: 2-year standard warranty included.
【Parameter List】
| Standard | optional | ||||||||||
| System | CPU | Intel Core i5-4200U (4th Gen) | Intel Core i3/i5/i7 (Gen 3/4/5/6/8/12) | ||||||||
| Frequency | 1.6 GHz (Up to 2.6 GHz) | / | |||||||||
| RAM | 8GB | 4GB / 8GB / 16GB | |||||||||
| SSD | 128GB | 64GB / 128GB / 256GB / 512GB | |||||||||
| Operating system | Windows 10 Pro | Windows 7 / Windows 11 / Linux | |||||||||
| Display | Screen | Industrial LCD Screen | / | ||||||||
| Resolution | 1024*768 | / | |||||||||
| Viewing angle | 85/85/85/85 (Typ.) (CR≥10) Full Viewing Angle | / | |||||||||
| Contrast ratio | 1000:1 | / | |||||||||
| Brightness | 350cd/m2 | 500/1000 cd/m2 | |||||||||
| Screen scale | / | / | |||||||||
| Network | Wi-Fi | / | Single-band / Dual-band | ||||||||
| Ethernet | 1 x Gigabit Ethernet | / | |||||||||
| BT | Bluetooth (Optional) | / | |||||||||
| 4G LTE | / | Mobile / Unicom / Telecom | |||||||||
| Interfaces | USB | USB 2.0 * 2, USB 3.0 * 2 | / | ||||||||
| COM | COM * 4 (Expandable) | / | |||||||||
| HD | 1 | / | |||||||||
| VGA | 1 | / | |||||||||
| TF card slot | / | / | |||||||||
| LAN | 1 | Customizable2* | |||||||||
| SIM-4G | / | Customizable1* | |||||||||
| Multi-Media | DC-IN | 1 | / | ||||||||
| Video | / | / | |||||||||
| Audio | Audio-In*1 / Audio-Out*1 | Built-in Speaker | |||||||||
| Accessories | Picture | / | / | ||||||||
| Temperature | Adapter | AC 100-240V 50/60Hz, DC 12V/5A External Power Adapter | / | ||||||||
| Working temperature | -10°C ~ 60°C | / | |||||||||
| Mounting | Storage temperature | -20°C ~ 70°C | / | ||||||||
| VESA Mount | / | Customizable | |||||||||
| Panel Mount | / | Customizable | |||||||||
| Packaging | Stand Mount | / | Customizable | ||||||||
| Net weight | 2.3kg | / | |||||||||
| Gross weight | 3.35kg | / | |||||||||
| Product dimensions | （L*W*H） | / | |||||||||
| Single Unit Package Dimension | 49*34*13（L*W*H） | / | |||||||||
| Carton Dimension | 53*50*34（L*W*H）(Ctn Qty:5 pcs) | / | |||||||||
| Other functions | Camera | / | Customizable | ||||||||
| POE | / | Customizable | |||||||||
| OEM | Appearance, Interface, CPU, Logo, etc. | ||||||||||
Product Gallery
Applications
OEM / ODM Customization
